Argon 10 – Argon Gas Management System – Inert

Argon 10 – Argon Gas Management System – Inert

Argon 10 – Argon Gas Management System – Inert is a standalone solution designed for enclosures up to 12 m³, operating continuously with ultra-pure argon (<1 ppm O₂ and H₂O). It is engineered for high-throughput or large-volume setups, providing advanced gas purification and safety features.

Need more information, a price list or a quote? Contact the manufacturer

Request prices and options

Dual regenerable purification columns enable uninterrupted operation—while one purifies, the other regenerates.
High-flow blower – variable speed up to 185 CFM (315 m³/h) connected to an 80 mm stainless steel loop, ideal for large enclosures.
Stainless steel 304 chassis on casters, dimensions ~1.2 m × 1.27 m × 1.58 m, for easy mobility.
PLC-controlled 6″ touchscreen displays real-time pressure, O₂, and H₂O levels with 24-hour logging.
Automatic pressure control (± 15 mbar) synchronized with column valves to prevent start-up if isolation fails.
Regeneration and purge cycle automation restarts blower post-regeneration.
22 CFM rotary vane vacuum pump with oil mist eliminator and eco-mode for efficiency.
High purification capacity: 217 L of O₂ and 9 000 g H₂O absorption per column.
Gas supply: 99.995 % argon at 3.8 bar with 3–7 % hydrogen for regeneration, 250 L/min working flow, 30 L/min purge.
Optional accessories: gas analyzers, pumps, solvent removal units, heaters, and support modules.

Ideal for:

gloveboxes and sealed enclosures up to 12 m³ in additive manufacturing, fine chemical, microelectronic, or battery labs;
high-throughput or large-scale processes where atmospheric purity and stability are critical;
industries requiring traceability, safety, and continuous operation such as industrial labs, production lines, and maintenance units;
retrofitting existing systems with an upgraded, high-performance inert gas solution.

The Argon 10 – Inert delivers advanced atmospheric control with its dual regenerable purification, strong circulation flow, intelligent interface, and automated operation. It ensures a stable and traceable argon atmosphere, meeting stringent requirements for performance, safety, and compliance.
